图片名称

产品中心

+
  • 024-1.jpg
  • 024-2.jpg

SH-024系列丙烯酸改性有机硅树脂

本品由苯基、甲基单体水解的硅醇与特种丙烯酸单体经特殊工艺制备而成,兼具丙烯酸树脂和有机硅树脂的优点

所属分类:

硅树脂


在线咨询

产品描述

SH-024系列丙烯酸改性有机硅树脂

一、性能及用途

本品由苯基、甲基单体水解的硅醇与特种丙烯酸单体经特殊工艺制备而成,兼具丙烯酸树脂和有机硅树脂的特点,具有良好的耐热性和耐候性能,附着力强,光泽性好,可低温固化。适用于调配各种系列的耐高温涂料、耐候涂料以及H级有机硅绝缘漆等。



二、主要技术指标



牌号

024系列丙烯酸改性有机硅树脂

O242

0243

O244

O245

O246

外观

   无色至淡黄色液体,允许有乳白色光

固含量,%

50±1

粘度(涂-4杯,25℃),S

>120

>100

>80

>60

20~60

干燥时间,

表干0.5h,

烘干180℃ 0.5h

表干1h,

烘干180℃ 1h

耐热性(清漆:浮型铝粉=4:1 ,200-600±10℃,3h)

不脱落、不开裂、不起泡。



三、包装及贮运

本品用200KG铁桶包装,贮存于阴凉干燥处,防止阳光直射,避免与酸、碱接触,按危险品贮运。



四、施工参考

1、可采用双组分常温固化,与异氰酸酯类固化剂如拜耳3390、N75等配合使用,加量为树脂总量的10~20%;

2、高温烘烤固化,升温到180℃一个小时固化,也可与氨基树脂配合缩短固化时间;

3、本品含有甲苯、二甲苯等易燃易爆的溶剂,在加工过程中应注意加强现场通风,注意防火、防静电,严格断绝火源。操作人员应注意劳动保护。



Acrylic Acid Modified Organic Silicone Resin SH-024

Performance and Usage

This product is produced from silanol which is hydrolyzed from phenyl monomer, methyl monomer and special acrylic monomers by specific process.

It has the advantages of both acrylic resin and silicone resin, such as good heat resistance, anticorrosive properties, strong adhesion and good gloss. It can be solidified at low temperature. It is suitable for the preparation of various series of high temperature resistant coatings, weather resistant coatings and H grade organic silicon insulating paint.

Main technical index

Type

SH-024 series acrylic acid modified silicone resin

0242

0243

0244

0245

0246

Appearance

Colorless to light yellow transparent
liquid, opalescence is permitted

Solid content  %

50±1

Viscosity (4# cup,25℃,S)

>120

>100

>80

>60

20-60

Drying Time ≤

Surface drying 0.5h, drying by heating 180℃ 0.5h

Surface drying 1h, drying by heating 180℃ 1h

Heat resistance (Varnish: float type aluminum powder
=4:1 ,200-600 ±10℃,3h)

No peeling, no cracking, no blistering



Ⅲ Packaging, Storage & Delivery

This product is packed in 200 kg iron drum, stored in a cool and dry place, avoid direct sunlight, avoid acid and alkali contact. Storied and transported as dangerous goods.



Construction reference

1.It can be cured at room temperature with two components, combined with isocyanate curing agent such as Bayer 3390, N75, etc ,the addition amount is 10 ~ 20% of the total resin.

2.High temperature curing, heating up to 180℃ for one hour curing. It can also cooperate with amino resin to shorten curing time.

3.This product contains toluenexylene and other flammable and explosive solvents. Attention should be paid to enhancing site ventilation during processing. Pay attention to fire prevention, anti-static, strictly cut off fire sources. Operators should pay attention to labor protection.

推荐产品

在线咨询

立即咨询
